WELCOME TO THE VIESSMANN ACADEMY HOME PAGE!
BELOW IS OUR OPEN ENROLLMENT CLASS SCHEDULE WHICH IS UPDATED ON A QUARTERLY BASIS.
PLEASE CHECK BACK PERIODICALLY FOR TRAINING OPPORTUNITIES THAT FIT YOUR NEEDS!
TO ENSURE YOU GET THE MOST OUT OF YOUR TRAINING AND THAT THE CLASS YOU ATTEND MEET YOUR NEEDS, WE HAVE PROVIDED CLASS DESCRIPTIONS ALONG
WITH MODULE LEARNING OBJECTIVES FOR EACH CLASS. PLEASE REVIEW ALL PRIOR TO REGISTRATION!
PLEASE NOTE: OUR TRAINING CLASSES ARE FOR LICENSED HVAC PROFESSIONALS.
IF YOU ARE A HOMEOWNER PLEASE VISIT MYVIESSMANN.COM FOR ADDITIONAL RESOURCES.
UPCOMING OPEN ENROLLMENT CLASS SCHEDULE
WARWICK, RI
*Closed/Private Trainings will only be listed on the registration form*
ACADEMY LOCATION; 45 ACCESS ROAD, WARWICK, RI, 02886
Class Time : 8:15 AM Arrival | 4:15 Departure
Class Description: This class is for licensed contractors or service technicians that are beginning to or have been working with the Vitodens 100 B1HA/B1KA. This class will cover detailed information of all aspects of installation (mounting, piping, venting, gas supply, wiring, programming) and boiler startup. There will be hands on portions for control programming and boiler commissioning. Prior experience with condensing boiler installations or service is required.
Modules & Associated Learning Objectives Covered:
1. Boiler Details
- Explain the difference between the B1HA and B1KA and which applications each model is best suited for
- Identify two features of the new Vitodens 100 and how they help the installer
- Describe the qualities of the Viessmann radial heat exchanger and how it sets Viessmann apart from the others
- State the primary control logic of the new Vitodens 100
2. Mounting & Piping
- List a benefit of the four pipe connection design
- Explain the reason for primary / secondary piping
- Identify two benefits of a low loss header over closely spaced tees
- Explain why a condensate neutralizer is recommended and the two rules to follow when piping it
3. Venting
- Identify the 3 venting options
- Explain how equivalent lengths are calculated for venting
- Explain the difference between equivalent vent length and combined equivalent vent length
- Describe a possible cause of cross contamination in Coaxial Venting and in Two Pipe Venting
4. Gas Supply & Burner
- List the gas pressure ranges required for NG and LPG
- Explain the two step conversion procedure from NG to LPG
- List two primary tools required to check combustion
- State how often an emissions test must be performed
5. Wiring
- Explain the wiring requirements for the B1HA & for the B1KA
- List two devices that could enable the boiler for a heating demand
- Describe the two built-in methods of controlling an indirect water heater for the B1HA model
- Explain the two choices available for boiler supply temperature control
6. Control Interface & Start Up Programming
- Identify the control display symbols and what they indicate
- Explain the steps to access the control configuration codes
- Compare the difference of using outdoor sensor vs set point temperature
- Explain the steps to access the fault history
7. Start Up / Commissioning
- Explain the procedure for most effective purging of boiler after filling
- List the two electronic tools required to commission a B1HA / B1KA boiler
- Describe how to disengage burner for inspector using flow-switch
- Describe how to disengage burner for inspector using Fixed High Limit
Class Time : 8:15 AM Arrival | 4:15 Departure
Class Description:This class is for licensed contractors or service technicians that are beginning to or have been working with the Vitodens 100 B1HA/B1KA. This class will cover detailed information of annual service and maintenance requirements, control review, and basic troubleshooting. There will be hands on portions for boiler servicing, controls, and troubleshooting diagnosis. Prior experience with condensing boiler installations or service is required.
Modules & Associated Learning Objectives Covered:
1. Control Navigation
- Identify the display symbols and what they indicate
- List the steps to access the control configuration codes
- List the steps to access the fault history
- Describe the effects of adjusting the heating curve if used
2. Service / Maintenance
- Describe how to remove the burner assembly and the proper cleaning techniques
- List the recommended chemicals and tools to clean the heat exchanger
- Describe two maintenance tips to avoid condensate backup
3. Troubleshooting
- State the three requirements for combustion
- Explain the difference between the burner being in fault mode or being blocked
- List three no heat situations that would NOT be caused by the boiler
- List three no heat situations that would be caused by the boiler
Class Time : 8:15 AM Arrival | 4:15 Departure
Class Description: This class is for licensed contractors or service technicians that are beginning to or have been working with the Vitocrossal 300 CU3A. This class will cover detailed information of all aspects of installation (locating, venting, piping, gas supply, Lambda Pro, wiring, startup programming and wizard) and boiler startup. There will be hands on portions for control programming and boiler commissioning. Prior experience with condensing boiler installations or service is required.
Modules & Associated Learning Objectives Covered:
1. Boiler Details
- Identify two features of the CU3A model and how they can help the installer
- List some ideal applications for the Vitocrossal CU3A boiler
- Describe the qualities of the Viessmann Crossal Heat Exchanger and why it sets Viessmann apart from the rest
2. Installation & Piping
- Explain the benefits of high mass direct correct piping
- Identify the fitting connections and piping options
- Describe the function of the safety header
- Explain why a condensate neutralizer is recommended and the two rules to follow when piping it
3. Venting
- Identify the 3 venting options
- Explain how equivalent lengths are calculated for venting
- Explain the difference between equivalent vent length and combined equivalent vent length
- Describe a possible cause of cross contamination in Coaxial Venting and in Two Pipe Venting
4. Gas Supply & Burner
- List the gas pressure ranges required for NG and LPG
- Explain the two step conversion procedure from NG to LPG
- List two primary tools required to check combustion
- State how often an emissions test must be performed
5. Wiring
- Identify the line voltage, low voltage and sensor connections
- Describe the quality of the boiler control that sets Viessmann apart from the others
- Explain the two methods to wire the low water cut off
6. Control Interface & Start Up Programming
- Identify the HO1B control buttons and the home screen display symbols
- Explain the importance of correct time and date in control
- Describe the two choices of boiler temperature control when utilizing the Startup wizard
- Describe the process of selecting the proper heating curve and how to adjust them for different emitters
7. Boiler Start Up / Commissioning
- List the two electronic tools required to commission a CU3A boiler
- Describe how to disengage burner for inspector using LWCO
- Describe how to disengage burner for inspector using Fixed High Limit
Class Time : 8:15 AM Arrival | 4:15 Departure
Class Description: This class is for licensed contractors or service technicians that are beginning to or have been working with the Vitocrossal 300 CU3A. This class will cover detailed information of annual service and maintenance requirements, control review, and basic troubleshooting. There will be hands on portions for boiler servicing, control navigation, and troubleshooting diagnosis. Prior experience with condensing boiler installations or service is required.
Modules & Associated Learning Objectives Covered:
1. Control Navigation
- Identify the display symbols and what they indicate
- Demonstrate the steps to access the service level and coding level 2
- List the steps to access the fault history
- Describe the effects of adjusting the heating curve if used
2. Service / Maintenance
- Describe how to remove the burner assembly and the proper cleaning techniques
- List the recommended chemicals and tools to clean the heat exchanger
- Describe two maintenance tips to avoid condensate backup
3. Troubleshooting
- State the three requirements for combustion
- Explain the difference between the burner being in fault mode or being blocked
- List three no heat situations that would NOT be caused by the boiler
- List three no heat situations that would be caused by the boiler
Class Time : Day 1: 8:15 am arrival | 4:15 pm departure Day 2: 8:15 am arrival | 1:00 pm departure
Class Description: This class is for licensed contractors or service technicians that are interested in learning about the Vitodens 200 B2HA/B2HB boiler in a Multi Boiler Application, the Vitocrossal 200 CM2 & Vitocrossal 300 CA3. This class will cover a limited overview of all aspects of installation (mounting, piping, venting, gas supply, wiring, programming) and basic service requirements. There will be lab demonstration portions for control programming and boiler service. No prior experience with Viessmann boilers is required.
Modules & Associated Learning Objectives Covered:
1. Vitodens 200 Product Overview
- State several differences between the B2HA model and the B2HB model
- Identify some common applications for a Vitodens 200 model boiler
- List four features of the Vitodens 200 series boiler and their benefits
- Identify how many boilers can be cascaded as a group of boilers
2. Vitodens 200 Multi Boiler Overview
- Identify how many Vitodens 200 boilers and models can be used in the same application
- List the controls used and set up procedures
- Describe how to install and set up LON
- Describe the 2 methods of multi boiler installations
3. Vitodens 200 Service/Maintenance
- Describe how to remove the burner assembly & proper cleaning techniques
- List the recommended chemicals and tools to clean the heat exchanger
- Describe two maintenance tips to avoid condensate backup
- Identify steps to check the venting system for proper install
4. VItocrossal 200 CM2 Product Overview
- List sizes and the key features and benefits (incl. common applications)
- Describe shipping methods available
- Identify key benefits of each shipping method and when to apply
- List the available venting options
5. Vitocrossal 200 CM2 Service/Maintenance
- Identify the steps taken during an annual servicing
- Identify the recommended cleaning solution, tools and parts that may be needed
- Describe the need for a periodic or annual maintenance
6. VItocrossal 300 CA3B Product Overview
- List sizes and the key features and benefits (incl. common applications) > Describe shipping methods available
- Identify key benefits of each shipping methods and when to apply
- List the available venting options
7. VItocrossal 300 CA3B Service/Maintenance
- Identify the steps taken during an annual servicing
- Identify the recommended cleaning solution, tools and parts that may be needed
- Describe the need for a periodic or annual maintenance
Class Time : 8:15 am arrival | 4:15 pm departure
Class Description: This class is for licensed contractors or service technicians who are new to Viessmann and are interested in learning about the Vitodens 100 B1HA/B1KA, Vitocrossal 300 CU3A boilers. This class will cover a limited overview of all aspects of installation (mounting, piping, venting, gas supply, wiring, programming), including Lambda Pro & the start up wizard for the CU3A, and basic service requirements. There will be lab demonstration portions for control programming and boiler service. No prior experience with Viessmann boilers is required.
Modules & Associated Learning Objectives Covered:
1. Vitodens 100 B1HA/B1KA Product Overview
- Describe the difference of the B1HA model and the B1KA model
- Identify the suitable applications for the B1HA model and for the B1KA model
- List 4 features of the Vitodens 100 boiler and their benefits
- Identify the preferred method of piping for the Vitodens 100
2. Vitodens 100 B1HA/B1KA Service / Maintenance Overview
- Describe how to remove the burner assembly & proper cleaning techniques
- List the recommended chemicals and tools to clean the heat exchanger
- Describe two maintenance tips to avoid condensate backup
3. Vitocrossal 300 CU3A Product Overview
- Describe the primary difference between the CU3A boiler compared to typical wall hung ModCon boilers
- Identify common applications for a Vitocrossal CU3A model boiler
- List 4 features of the Vitocrossal CU3A boiler and their benefits
- Identify the most common method of piping for the CU3A
4. Vitocrossal 300 CU3A Service / Maintenance Overview
- Describe how to remove the burner assembly & proper cleaning techniques
- List the recommended chemicals and tools to clean the heat exchanger
- Describe two service steps to ensure condensate removal
Class Time : 8:15 am arrival | 4:15 pm departure
Class Description: This class is for licensed contractors or service technicians that are beginning to or have been working with the Vitodens 200 B2HA/B2HB. This class will cover detailed information of all aspects of installation (mounting, piping, venting, gas supply, Lambda Pro, wiring, startup programming, and wizard) and boiler startup. There will be hands-on portions for control programming and boiler commissioning. Prior experience with condensing boiler installations or service is required.
Modules & Associated Learning Objectives Covered:
1. Boiler Details
- Explain when to select a Vitodens 200 series boiler over the 100 series
- Identify two features of the Vitodens 200 model and how they help the installer
- List some ideal applications for the Vitodens 200 boiler
- Describe the qualities of the Viessmann radial heat exchanger and how it sets Viessmann apart from the others
2. Mounting & Piping
- Explain the need for primary/secondary piping
- Explain the importance of correct water flow rate through the 200 boiler
- Explain the effects of piping the DHW on the boiler side or off the system side
- Explain why a condensate neutralizer is recommended and the two rules to follow when piping it
3. Venting
- Identify the 3 venting options
- Explain how equivalent lengths are calculated for venting
- Explain the difference between equivalent vent length and combined equivalent vent length
- Describe a possible cause of cross-contamination in Coaxial Venting and in Two Pipe Venting
4. Gas Supply & Burner
- List the gas pressure ranges required for NG and LPG
- Explain the two-step conversion procedure from NG to LPG
- List two primary tools required to check combustion
- State how often an emissions test must be performed
5. Wiring
- Identify the line voltage, low voltage, and sensor connections
- Describe the quality of the boiler control that sets Viessmann apart from the others
- Describe the function of the boiler flow switch(es)
- Explain the two methods to wire the low water cut off
6. Control Interface & Start-Up Programming
- Identify the HO1B control buttons and the home screen display symbols
- Explain the importance of correct time and date in the control
- Describe the two choices of boiler temperature control when utilizing the Startup wizard
- Describe the process of selecting the proper heating curve and how to adjust them for different emitters
7. Boiler Start-Up / Commissioning
- Explain one step to follow for more effective purging of the boiler while filling
- List the two electronic tools required to commission a B2HA / B2HB boiler
- Describe how to disengage burner for inspector using flow-switch
- Describe how to disengage burner for inspector using Fixed High Limit
Class Time : Day 1: 8:15 am arrival | 4:15 pm departure Day 2: 8:15 am arrival | 1:00 pm departure
Class Description: This class is for licensed contractors or service technicians that are interested in learning about the Vitodens 200 B2HA/B2HB boiler in a Multi Boiler Application, the Vitocrossal 200 CM2 & Vitocrossal 300 CA3. This class will cover a limited overview of all aspects of installation (mounting, piping, venting, gas supply, wiring, programming) and basic service requirements. There will be lab demonstration portions for control programming and boiler service. No prior experience with Viessmann boilers is required.
Modules & Associated Learning Objectives Covered:
1. Vitodens 200 Product Overview
- State several differences between the B2HA model and the B2HB model
- Identify some common applications for a Vitodens 200 model boiler
- List four features of the Vitodens 200 series boiler and their benefits
- Identify how many boilers can be cascaded as a group of boilers
2. Vitodens 200 Multi Boiler Overview
- Identify how many Vitodens 200 boilers and models can be used in the same application
- List the controls used and set up procedures
- Describe how to install and set up LON
- Describe the 2 methods of multi boiler installations
3. Vitodens 200 Service/Maintenance
- Describe how to remove the burner assembly & proper cleaning techniques
- List the recommended chemicals and tools to clean the heat exchanger
- Describe two maintenance tips to avoid condensate backup
- Identify steps to check the venting system for proper install
4. VItocrossal 200 CM2 Product Overview
- List sizes and the key features and benefits (incl. common applications)
- Describe shipping methods available
- Identify key benefits of each shipping method and when to apply
- List the available venting options
5. Vitocrossal 200 CM2 Service/Maintenance
- Identify the steps taken during an annual servicing
- Identify the recommended cleaning solution, tools, and parts that may be needed
- Describe the need for a periodic or annual maintenance
6. VItocrossal 300 CA3B Product Overview
- List sizes and the key features and benefits (incl. common applications)
- Describe shipping methods available
- Identify key benefits of each shipping methods and when to apply
- List the available venting options
7. VItocrossal 300 CA3B Service/Maintenance
- Identify the steps taken during an annual servicing
- Identify the recommended cleaning solution, tools, and parts that may be needed
- Describe the need for a periodic or annual maintenance
Class Time : 8:15 AM Arrival | 4:15 Departure
Class Description: This class is for licensed contractors or service technicians that are beginning to or have been working with the Vitodens 100 B1HA/B1KA. This class will cover detailed information on all aspects of installation (mounting, piping, venting, gas supply, wiring, programming) and boiler startup. There will be hands-on portions for control programming and boiler commissioning. Prior experience with condensing boiler installations or service is required.
Modules & Associated Learning Objectives Covered:
1. Boiler Details
- Explain the difference between the B1HA and B1KA and which applications each model is best suited for
- Identify two features of the new Vitodens 100 and how they help the installer
- Describe the qualities of the Viessmann radial heat exchanger and how it sets Viessmann apart from the others
- State the primary control logic of the new Vitodens 100
2. Mounting & Piping
- List a benefit of the four-pipe connection design
- Explain the reason for primary/secondary piping
- Identify two benefits of a low loss header over closely spaced tees
- Explain why a condensate neutralizer is recommended and the two rules to follow when piping it
3. Venting
- Identify the 3 venting options
- Explain how equivalent lengths are calculated for venting
- Explain the difference between equivalent vent length and combined equivalent vent length
- Describe a possible cause of cross-contamination in Coaxial Venting and in Two Pipe Venting
4. Gas Supply & Burner
- List the gas pressure ranges required for NG and LPG
- Explain the two-step conversion procedure from NG to LPG
- List two primary tools required to check combustion
- State how often an emissions test must be performed
5. Wiring
- Explain the wiring requirements for the B1HA & for the B1KA
- List two devices that could enable the boiler for a heating demand
- Describe the two built-in methods of controlling an indirect water heater for the B1HA model
- Explain the two choices available for boiler supply temperature control
6. Control Interface & Start-Up Programming
- Identify the control display symbols and what they indicate
- Explain the steps to access the control configuration codes
- Compare the difference of using outdoor sensor vs setpoint temperature
- Explain the steps to access the fault history
7. Start-Up / Commissioning
- Explain the procedure for most effective purging of boiler after filling
- List the two electronic tools required to commission a B1HA / B1KA boiler
- Describe how to disengage burner for inspector using flow-switch
- Describe how to disengage burner for inspector using Fixed High Limit
Class Time : 8:15 AM Arrival | 4:15 Departure
Class Description: This class is for licensed contractors or service technicians that are beginning to or have been working with the Vitodens 100 B1HA/B1KA. This class will cover detailed information on annual service and maintenance requirements, control review, and basic troubleshooting. There will be hands-on portions for boiler servicing, controls, and troubleshooting diagnosis. Prior experience with condensing boiler installations or service is required.
Modules & Associated Learning Objectives Covered:
1. Control Navigation
- Identify the display symbols and what they indicate
- List the steps to access the control configuration codes
- List the steps to access the fault history
- Describe the effects of adjusting the heating curve if used
2. Service / Maintenance
- Describe how to remove the burner assembly and the proper cleaning techniques
- List the recommended chemicals and tools to clean the heat exchanger
- Describe two maintenance tips to avoid condensate backup
3. Troubleshooting
- State the three requirements for combustion
- Explain the difference between the burner being in fault mode or being blocked
- List three no heat situations that would NOT be caused by the boiler
- List three no heat situations that would be caused by the boiler
Class Time : 8:15 AM Arrival | 4:15 Departure
Class Description: This class is for licensed contractors or service technicians that are beginning to or have been working with the Vitocrossal 300 CU3A. This class will cover detailed information on annual service and maintenance requirements, control review, and basic troubleshooting. There will be hands-on portions for boiler servicing, control navigation, and troubleshooting diagnosis. Prior experience with condensing boiler installations or service is required.
Modules & Associated Learning Objectives Covered:
1. Control Navigation
- Identify the display symbols and what they indicate
- Demonstrate the steps to access the service level and coding level 2
- List the steps to access the fault history
- Describe the effects of adjusting the heating curve if used
2. Service / Maintenance
- Describe how to remove the burner assembly and the proper cleaning techniques
- List the recommended chemicals and tools to clean the heat exchanger
- Describe two maintenance tips to avoid condensate backup
3. Troubleshooting
- State the three requirements for combustion
- Explain the difference between the burner being in fault mode or being blocked
- List three no heat situations that would NOT be caused by the boiler
- List three no heat situations that would be caused by the boiler
Class Time : 8:15 AM Arrival | 4:15 Departure
Class Description: This class is for licensed contractors or service technicians that are beginning to or have been working with the Vitodens 200 B2HA/B2HB. This class will cover detailed information on annual service and maintenance requirements, control review, and basic troubleshooting. There will be hands-on portions for boiler servicing, control navigation, and troubleshooting diagnosis. Prior experience with condensing boiler installations or service is required.
Modules & Associated Learning Objectives Covered:
1. Control Navigation
- Identify the display symbols and what they indicate
- Demonstrate the steps to access the service level and coding level 2
- List the steps to access the fault history
- Describe the effects of adjusting the heating curve if used
2. Service / Maintenance
- Describe how to remove the burner assembly and the proper cleaning techniques
- List the recommended chemicals and tools to clean the heat exchanger
- Describe two maintenance tips to avoid condensate backup
3. Troubleshooting
- State the three requirements for combustion
- Explain the difference between the burner being in fault mode or being blocked
- List three no heat situations that would NOT be caused by the boiler
- List three no heat situations that would be caused by the boiler
Class Time : Day 1: 8:15 am arrival | 4:15 pm departure Day 2: 8:15 am arrival | 1:00 pm departure
Class Description: This class is for licensed contractors or service technicians that are interested in learning about the Vitodens 200 B2HA/B2HB boiler in a Multi Boiler Application, the Vitocrossal 200 CM2 & Vitocrossal 300 CA3. This class will cover a limited overview of all aspects of installation (mounting, piping, venting, gas supply, wiring, programming) and basic service requirements. There will be lab demonstration portions for control programming and boiler service. No prior experience with Viessmann boilers is required.
Modules & Associated Learning Objectives Covered:
1. Vitodens 200 Product Overview
- State several differences between the B2HA model and the B2HB model
- Identify some common applications for a Vitodens 200 model boiler
- List four features of the Vitodens 200 series boiler and their benefits
- Identify how many boilers can be cascaded as a group of boilers
2. Vitodens 200 Multi Boiler Overview
- Identify how many Vitodens 200 boilers and models can be used in the same application
- List the controls used and set up procedures
- Describe how to install and set up LON
- Describe the 2 methods of multi boiler installations
3. Vitodens 200 Service/Maintenance
- Describe how to remove the burner assembly & proper cleaning techniques
- List the recommended chemicals and tools to clean the heat exchanger
- Describe two maintenance tips to avoid condensate backup
- Identify steps to check the venting system for proper install
4. VItocrossal 200 CM2 Product Overview
- List sizes and the key features and benefits (incl. common applications)
- Describe shipping methods available
- Identify key benefits of each shipping method and when to apply
- List the available venting options
5. Vitocrossal 200 CM2 Service/Maintenance
- Identify the steps taken during an annual servicing
- Identify the recommended cleaning solution, tools, and parts that may be needed
- Describe the need for a periodic or annual maintenance
6. VItocrossal 300 CA3B Product Overview
- List sizes and the key features and benefits (incl. common applications)
- Describe shipping methods available
- Identify key benefits of each shipping methods and when to apply
- List the available venting options
7. VItocrossal 300 CA3B Service/Maintenance
- Identify the steps taken during an annual servicing
- Identify the recommended cleaning solution, tools, and parts that may be needed
- Describe the need for a periodic or annual maintenance
UPCOMING OPEN ENROLLMENT CLASS SCHEDULE
SILICON VALLEY, CA
*Closed/Private Trainings will only be listed on the registration form*
ACADEMY LOCATION: 1465 N. MILPITAS BLVD, MILPITAS, CA, 95035
Class Time : 8:45 AM Arrival | 4:15 Departure
Class Description: This class is for licensed contractors or service technicians that are beginning to or have been working with the Vitocrossal 300 CU3A. This class will cover detailed information on annual service and maintenance requirements, control review, and basic troubleshooting. Prior experience with condensing boiler installations or service is required.
Modules & Associated Learning Objectives Covered:
1. Control Navigation
- Identify the display symbols and what they indicate
- Demonstrate the steps to access the service level and coding level 2
- List the steps to access the fault history
- Describe the effects of adjusting the heating curve if used
2. Service / Maintenance
- Describe how to remove the burner assembly and the proper cleaning techniques
- List the recommended chemicals and tools to clean the heat exchanger
- Describe two maintenance tips to avoid condensate backup
3. Troubleshooting
- State the three requirements for combustion
- Explain the difference between the burner being in fault mode or being blocked
- List three no heat situations that would NOT be caused by the boiler
- List three no heat situations that would be caused by the boiler
Class Time : 8:45 AM Arrival | 4:15 Departure
Class Description: This class is for licensed contractors or service technicians that are interested in learning about the Vitodens 200 Cascade Systems, Vitocrossal 200 CM2 & Vitocrossal 300 CA3B boilers. This class will cover a limited overview of all aspects of installation (piping, venting, gas supply, wiring, programming, start-up wizard) and basic service requirements. No prior experience with Viessmann boilers is required.
Modules & Associated Learning Objectives Covered:
1. Vitodens 200 Product Overview
- State several differences between the B2HA model and the B2HB model
- Identify some common applications for a Vitodens 200 model boiler
- List four features of the Vitodens 200 series boiler and their benefits
- Identify how many boilers can be cascaded as a group of boilers
2. Vitodens 200 Multi Boiler Overview
- Identify how many Vitodens 200 boilers and models can be used in the same application
- List the controls used and set up procedures
- Describe how to install and set up LON
- Describe the 2 methods of multi boiler installations
3. Vitodens 200 Service/Maintenance
- Describe how to remove the burner assembly & proper cleaning techniques
- List the recommended chemicals and tools to clean the heat exchanger
- Describe two maintenance tips to avoid condensate backup
- Identify steps to check the venting system for proper install
4. Vitocrossal 200 CM2 Product Overview
- List sizes and the key features and benefits (incl. common applications) > Describe shipping methods available
- Identify key benefits of each shipping method and when to apply
- List the available venting options
5. Vitocrossal 200 CM2 Service/Maintenance
- Identify the steps taken during an annual servicing
- Identify the recommended cleaning solution, tools, and parts that may be needed
- Describe the need for a periodic or annual maintenance
6. VItocrossal 300 CA3B Product Overview
- List sizes and the key features and benefits (incl. common applications)
- Describe shipping methods available
- Identify key benefits of each shipping methods and when to apply
- List the available venting options
7. VItocrossal 300 CA3B Service/Maintenance
- Identify the steps taken during an annual servicing
- Identify the recommended cleaning solution, tools, and parts that may be needed
- Describe the need for a periodic or annual maintenance
Class Time : 8:45 AM Arrival | 4:15 Departure
Class Description: This class is for licensed contractors or service technicians that are beginning to or have been working with the Vitodens 200 B2HA/B2HB. This class will cover detailed information on all aspects of the installation (mounting, piping, venting, gas supply, Lambda Pro, wiring, startup programming, and wizard) and boiler startup. There will be hands-on portions for control programming and boiler commissioning. Prior experience with condensing boiler installations or service is required.
Modules & Associated Learning Objectives Covered:
1. Boiler Details
- Explain when to select a Vitodens 200 series boiler over the 100 series
- Identify two features of the Vitodens 200 model and how they help the installer
- List some ideal applications for the Vitodens 200 boiler
- Describe the qualities of the Viessmann radial heat exchanger and how it sets Viessmann apart from the others
2. Mounting & Piping
- Explain the need for primary/secondary piping
- Explain the importance of correct water flow rate through the 200 boiler
- Explain the effects of piping the DHW on the boiler side or off the system side
- Explain why a condensate neutralizer is recommended and the two rules to follow when piping it
3. Venting
- Identify the 3 venting options
- Explain how equivalent lengths are calculated for venting
- Explain the difference between equivalent vent length and combined equivalent vent length
- Describe a possible cause of cross-contamination in Coaxial Venting and in Two Pipe Venting
4. Gas Supply & Burner
- List the gas pressure ranges required for NG and LPG
- Explain the two-step conversion procedure from NG to LPG
- List two primary tools required to check combustion
- State how often an emissions test must be performed
5. Wiring
- Identify the line voltage, low voltage, and sensor connections
- Describe the quality of the boiler control that sets Viessmann apart from the others
- Describe the function of the boiler flow switch(es)
- Explain the two methods to wire the low water cut off
6. Control Interface & Start-Up Programming
- Identify the HO1B control buttons and the home screen display symbols
- Explain the importance of correct time and date in the control
- Describe the two choices of boiler temperature control when utilizing the Startup wizard
- Describe the process of selecting the proper heating curve and how to adjust them for different emitters
7. Boiler Start-Up / Commissioning
- Explain one step to follow for more effective purging of the boiler while filling
- List the two electronic tools required to commission a B2HA / B2HB boiler
- Describe how to disengage burner for inspector using flow-switch
- Describe how to disengage burner for inspector using Fixed High Limit
Class Time : 8:45 AM Arrival | 4:15 Departure
Class Description: This class is for licensed contractors or service technicians that are beginning to or have been working with the Vitodens 100 B1HA/B1KA. This class will cover detailed information on all aspects of installation (mounting, piping, venting, gas supply, wiring, programming) and boiler startup. Prior experience with condensing boiler installations or service is required.
Modules & Associated Learning Objectives Covered:
1. Boiler Details
- Explain the difference between the B1HA and B1KA and which applications each model is best suited for
- Identify two features of the new Vitodens 100 and how they help the installer
- Describe the qualities of the Viessmann radial heat exchanger and how it sets Viessmann apart from the others
- State the primary control logic of the new Vitodens 100
2. Mounting & Piping
- List a benefit of the four-pipe connection design
- Explain the reason for primary / secondary piping
- Identify two benefits of a low loss header over closely spaced tees
- Explain why a condensate neutralizer is recommended and the two rules to follow when piping it
3. Venting
- Identify the 3 venting options
- Explain how equivalent lengths are calculated for venting
- Explain the difference between equivalent vent length and combined equivalent vent length
- Describe a possible cause of cross-contamination in Coaxial Venting and in Two Pipe Venting
4. Gas Supply & Burner
- List the gas pressure ranges required for NG and LPG
- Explain the two-step conversion procedure from NG to LPG
- List two primary tools required to check combustion
- State how often an emissions test must be performed
5. Wiring
- Explain the wiring requirements for the B1HA & for the B1KA
- List two devices that could enable the boiler for a heating demand
- Describe the two built-in methods of controlling an indirect water heater for the B1HA model
- Explain the two choices available for boiler supply temperature control
6. Control Interface & Start-Up Programming
- Identify the control display symbols and what they indicate
- Explain the steps to access the control configuration codes
- Compare the difference of using outdoor sensor vs setpoint temperature
- Explain the steps to access the fault history
7. Start-Up / Commissioning
- Explain the procedure for most effective purging of boiler after filling
- List the two electronic tools required to commission a B1HA / B1KA boiler
- Describe how to disengage burner for inspector using flow-switch
- Describe how to disengage burner for inspector using Fixed High Limit
Class Time : 8:45 AM Arrival | 4:15 Departure
Class Description: This class is for licensed contractors or service technicians that are beginning to or have been working with the Vitodens 100 B1HA/B1KA. This class will cover detailed information of annual service and maintenance requirements, control review, and basic troubleshooting. Prior experience with condensing boiler installations or service is required.
Modules & Associated Learning Objectives Covered:
1. Control Navigation
- Identify the display symbols and what they indicate
- List the steps to access the control configuration codes
- List the steps to access the fault history
- Describe the effects of adjusting the heating curve if used
2. Service / Maintenance
- Describe how to remove the burner assembly and the proper cleaning techniques
- List the recommended chemicals and tools to clean the heat exchanger
- Describe two maintenance tips to avoid condensate backup
3. Troubleshooting
- State the three requirements for combustion
- Explain the difference between the burner being in fault mode or being blocked
- List three no heat situations that would NOT be caused by the boiler
- List three no heat situations that would be caused by the boiler
Class Time : 8:45 AM Arrival | 4:15 Departure
Class Description: This class is for licensed contractors or service technicians that are beginning to or have been working with the Vitocrossal 300 CU3A. This class will cover detailed information of all aspects of installation (locating, venting, piping, gas supply, Lambda Pro, wiring, startup programming, and wizard) and boiler startup. Prior experience with condensing boiler installations or service is required.
Modules & Associated Learning Objectives Covered:
1. Boiler Details
- Identify two features of the CU3A model and how they can help the installer
- List some ideal applications for the Vitocrossal CU3A boiler
- Describe the qualities of the Viessmann Crossal Heat Exchanger and why it sets Viessmann apart from the rest
2. Installation & Piping
- Explain the benefits of high mass direct correct piping
- Identify the fitting connections and piping options
- Describe the function of the safety header
- Explain why a condensate neutralizer is recommended and the two rules to follow when piping it
3. Venting
- Identify the 3 venting options
- Explain how equivalent lengths are calculated for venting
- Explain the difference between equivalent vent length and combined equivalent vent length
- Describe a possible cause of cross-contamination in Coaxial Venting and in Two Pipe Venting
4. Gas Supply & Burner
- List the gas pressure ranges required for NG and LPG
- Explain the two-step conversion procedure from NG to LPG
- List two primary tools required to check combustion
- State how often an emissions test must be performed
5. Wiring
- Identify the line voltage, low voltage, and sensor connections
- Describe the quality of the boiler control that sets Viessmann apart from the others
- Explain the two methods to wire the low water cut off
6. Control Interface & Start-Up Programming
- Identify the HO1B control buttons and the home screen display symbols
- Explain the importance of correct time and date in the control
- Describe the two choices of boiler temperature control when utilizing the Startup wizard
- Describe the process of selecting the proper heating curve and how to adjust them for different emitters
7. Boiler Start-Up / Commissioning
- List the two electronic tools required to commission a CU3A boiler
- Describe how to disengage burner for inspector using LWCO
- Describe how to disengage burner for inspector using Fixed High Limit
Class Time : 8:45 AM Arrival | 4:15 Departure
Class Description: This class is for licensed contractors or service technicians who are new to Viessmann and are interested in learning about the Viessmann Residential Gas Boilers. This class will cover a limited overview of all aspects of the installation (mounting, piping, venting, gas supply, wiring, programming) and basic service requirements of each boiler. No prior experience with Viessmann boilers is required.
Modules & Associated Learning Objectives Covered:
1. Vitodens 100 B1HA/B1KA Product Overview
- Describe the difference of the B1HA model and the B1KA model
- Identify the suitable applications for the B1HA model and for the B1KA model
- List 4 features of the Vitodens 100 boiler and their benefits
- Identify the preferred method of piping for the Vitodens 100
2. Vitodens 100 Service/Maintenance
- Describe how to remove the burner assembly & proper cleaning techniques
- List the recommended chemicals and tools to clean the heat exchanger
- Describe two maintenance tips to avoid condensate backup
3. Vitodnes 200 Product Overview
- State several differences between the B2HA model and the B2HB model
- Identify common applications for a Vitodens 200 model boiler
- List 4 features of the Vitodens 200 series boiler and their benefits
- Identify how many boilers can be cascaded as a group of boilers
4. Vitodens 200 Service Overview
- Describe how to remove the burner assembly & proper cleaning techniques
- List the recommended chemicals and tools to clean the heat exchanger
- Describe two maintenance tips to avoid condensate backup
5. VItodens 222 Product Overview
- Identify the suitable applications for a Vitodens 222-F model boiler
- Describe a unique feature of the 222-F boiler and how it benefits the homeowner
- Describe a unique feature of the 222-F boiler and how it benefits the installer
- Identify the preferred method of piping for the Vitodens 222-F
6. Vitodens 222 Service Overview
- Describe how to remove the burner assembly & proper cleaning techniques
- List the recommended chemicals and tools to clean the heat exchanger
- Describe two maintenance tips to avoid condensate backup
7. Vitocrossal 300 CU3A Product Overview
- Describe the primary difference between the CU3A boiler compared to typical wall hung ModCon boilers
- Identify common applications for a Vitocrossal CU3A model boiler
- List 4 features of the Vitocrossal CU3A boiler and their benefits
- Identify the most common method of piping for the CU3A
8. Vitocrossal 300 CU3A Service/Maintenance
- Describe how to remove the burner assembly & proper cleaning techniques
- List the recommended chemicals and tools to clean the heat exchanger
- Describe two service steps to ensure condensate removal
UPCOMING WEBINAR SCHEDULE
Once registered – you will receive a calendar invite for the webinar(s) you have chosen.
The link to join will be in the description of the calendar event
1 PDH CREDIT AVAILABLE FOR THOSE THAT ATTEND LIVE
STATEMENT OF PURPOSE: Hydronic system performance is highly dependent on the quality of the system fill water, both from an efficiency and longevity standpoint. In this presentation, we will examine the hydronic system and the quality of the water used to fill it. In most applications municipal or well water on site is used to fill the hydronic system. Domestic water may be suitable to consume but due to pH, hardness or other compounds dissolved in the water, the water may have adverse effects on the system. We will look at how these compounds enter the water and the potential problems that dissolved compounds present to the system. Additionally, we will look at the various methods of removing these compounds either in the fill process or through chemical addition. Finally, the various common additives for hydronic systems will be presented.
WEBINAR DESCRIPTION: This one-hour presentation will explore solar thermal water heating as it applies to domestic hot water production for residential applications with a review of basic solar principles and site considerations for optimum collector performance. Topics will include basic system sizing and design, system piping layout options, and protection against system overheating. Tune in for an engaging presentation about harvesting free thermal energy from the sun.
Meet the team you will interact with when attending a Viessmann Academy Training Class and who to contact for assistance!
Training at your fingertips! View our Video Library for quick 3-5 minute videos on our products – including step by step instructions on important programming and troubleshooting situations and MORE!
Access Viessmann’s library of product technical data manuals, warranty information, white papers, and more!
COMING SOON!
Explore what training options you have at the Viessmann Academy! Including our standard Viessmann Training Classes and all individuals modules you can choose from when requesting a customized class for you and your colleagues!
